Honeywell XNX User Manual

XNX Universal Transmitter Quick Start Guide
75
Fault Description
Appli-
cable
Sensors
Latching/
Non-Latch-
ing
Frequencyof
Diagnostic
EventHistoryData ActionForResolution
F127 Beam Block Excel Non-latching
XNX polls sen- sor every 2 sec- onds, diagnos- tic frequency controlled by sensor
Sensor fault or warning code (Note 4)
Check location for external interference or obstructions in the IR path. Check sensor for dirty windows. Check Excel alignment.
F128
Sensor Installation Not Complete
Excel Non-latching
XNX polls sen- sor every 2 sec- onds, diagnos- tic frequency controlled by sensor
Sensor fault or warning code (Note 4)
Check Excel alignment. Perform a zero calibration.
F130
Option Communi- cation Failure
All Non-latching 2 seconds
Option module ID: 0=None, 1=Foundation Fieldbus, 2=Mod- bus, 3=Relay
Check that installed option matches the option indicated in the XNX part number. If the option has been changed, the new option must be set up in Information- >Transmitter Data as described in the manual.
F133 Not used F143
Stabilization Timeout
All Latching 2 seconds Warm up time (seconds x100)
Cycle power, contact Honeywell Analytics’ Service Department if problem persists.

Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
