Linear actuators MC250 • MC253 • MC500 • MC503
Operating Manual Version 2.1 - March 2011 11
2.6 Ratingplate
The rating plate is located on the linear actuator casing.
This includes the type designation and the fabrication number (F.No.) with the
date of manufacture (last four digits).
 2.1 Components on page 6
3 Transport and storage
CAUTION
Risk of injury in the event of non-compliance with safety regulations!
• Wear the necessary personal and other safety equipment.
• Avoid knocks, shocks, vibrations and similar to the linear actuator.
• Store the linear actuator (and if necessary the complete actuating unit) in a dry
place.
• Observe the transportation and storage temperature of -20 to +65°C.
Input signal Y/
Input resistor (resistance
of load)
• 0 … 10 V DC / 77 k
• 2 … 10 V DC / 77 k
• 0 … 20 mA / 510 
• 4 … 20 mA / 510 
Output signal X/
Load capacity
• 0 … 10 V DC / resistance of load 1200 , I
max.
8 mA
• 0 … 20 mA / resistance of load
500  -
with printed circuit board for output signal as optional
extra (111)
• 4 … 20 mA / resistance of load 500  -
with printed circuit board for output signal as optional
extra (111)
Feedback signal R/Load
capacity
• 24 V DC / Minimum resistance
480 I
max.
35 mA
Transmission resistance
between B1 and B2
•max. 10

Table 2 Technical Data Signals
Diagram 4 Example of a rating plate
MC500/230
F.-Nr.: 07204142/01/0607
AC 50 Hz 230 V
Y=0
…10 V DC
X=0…10 V DC
max. 25 VA
IP 54
S3-50% ED
5kN
5s/mm
Stroke 60 mm
