HOUNO C 1.08 - Electrical Connection and Supply Lines

- 9 -
Installation and Connection
Electrical connection/survey of supply lines
The electrical connection must be carried out by an authorised electrician in accordance with
existing rules and regulations.
The wiring diagram is located in the motor compartment.
The terminal for the electrical connection is located behind the right side plate.
An approved plug outlet or a safety cutout must be located close to the oven so that
the oven can be disconnected during installation and repair. The safety cutout must be
able to cut off all poles with a total distance of break of at least 3 mm. Each of the two
units in a stacked arrangement (CombiPlus) must have its own plug outlet or safety cut-
out.
The warranty does not cover incorrect connection.
Supply lines - survey (applies to all models (C, B, K, CPE, BPE, KPE)
(All cross sections in mm² )
1.06 1.06
1.08 - 1.10 -
1.12
1.08 - 1.10 -
1.12
1.16 1.16 1.20 1.20
2.10
2.14
2.10
2.14
9 kW Fuse 18 kW Fuse 24 kW Fuse 36 kW Fuse 27 kW Fuse
400V 3N ~ 50/60 Hz 5x2,5 16A 5x4 35A 5x10 50A 5x16 63A 5x10 50A
400V 3 ~ 50/60 Hz 4x2,5 16A 4x4 35A 4x10 50A 4x16 63A 4x10 50A
415V 3N ~ 50/60 Hz 5x2,5 16A 5x4 25A 5x10 50A 5x10 50A 5x10 50A
440V 3 ~ 50/60 Hz 4x2,5 16A 4x4 25A 4x10 50A 4x10 50A 4x6 35A
200V 3 ~ 50/60 Hz 4x4 35A 4x16 63A 4x25 100A 4x35 125A 4x25 80A
230V 3 ~ 50/60 Hz 4x4 25A 4x10 50A 4x25 80A 4x35 100A 4x25 80A
230V 1 ~ 50/60 Hz 3x10 50A 3x25 80A * * * * * *
480V 3 ~ 50/60 Hz 4x2,5 16A 4x4 25A 4x6 35A 4x10 50A 4x6 35A
208V 3 ~ 50/60 Hz 4x4 25A 4x10 50A 4x25 80A 4x35 100A 4x25 80A
* Not possible
Recommended supply line: H07RN-F
