7. SERVICE INSTRUCTIONS
FUSE
Summary:
This service instruction outlines the procedure to replace the battery fuse in the control box.
Tools Required:
• T20 torx screwdriver
Parts Required:
• 1x T10AH250V M205 (Ø5mm x 20mm long) ceramic fuse
Location:
The fuse is stored in the control box located at the head end (HE) of the deck. It is housed under the plastic cover
without the LED light.
WARNING: The fuse is only to be replaced by service
personnel.
Procedure:
1. Raise the deck to the maximum height position and apply castor
brakes.
2. Unplug the power cord from the mains supply.
3. Using a T20 Torx screwdriver, remove the four screws from the
cover. Lift off the cover and set aside.
4. Remove fuse holder from the plastic slots
5. Remove the fuse from the plastic holder by pressing the holder
together and twisting anti-clockwise.
6. Remove the old fuse and replace with T10AH250V M205
ceramic fuse.
7. Fit fuse holder back into the plastic slots on the control box.
8. Finish by reversing the procedure from step 3.
9. Verify all stretcher functions are working correctly before returning
to service.
