Technical Service Manual M9 Transfer Stretcher (M999-29, Version 11, June 2021) 25
the plug port. Unplug the actuator cable.
7. Using a 5mm hex key and a 13mm spanner, disconnect
the actuator by removing the two shoulder bolts holding
the actuator at both ends.
8. Reverse the procedure to install the new HI-LO lift
actuator (see warning above).
9. Plug the power cord into the mains supply.
10. Perform control box reset procedure. (See Instructions For
Use) or (See “Control System Troubleshooting Table” on
page 36)
11. Verify all stretcher functions are working correctly before
returning to service.
HILO LIFT ACTUATOR continued.
7. SERVICE INSTRUCTIONS
Figure 9. Castor orientation when rolling
the stretcher onto its side.
