Technical Service Manual M9 Transfer Stretcher (M999-29, Version 11, June 2021) 41
11. BOGIE & ELEVATORS
ITEM NO. PART NO. DESCRIPTION QTY. REFERENCE
1 CRRM801 150 LINEA CASTOR - BRAKE 2 See note
2 CRRM802 150 LINEA CASTOR - BRAKE & STEER 1 See note
3 CRRM803 150 LINEA CASTOR - BRAKE & A/STATIC 1 See note
4 ELRM9603 HI-LO ACTUATOR 2
5 M702-17 BRAKE ROD GUIDE 3
6 M702-30 CASTOR PEDAL 4
7 M703-25 PIVOT BLOCK (TOP) 4
8 M703-26 PIVOT BLOCK (BOTTOM) 4
9 M703-30 ELEVATOR PLUG 4
10 M703-33 ELEVATOR HALF BUSH 8
11 M802-50 PEDAL INSERT RED 4
12 M802-51 PEDAL INSERT GREEN 4
13 M901-05 BOGIE ASSY M9 STRETCHER 1
14 M901-40 BOGIE COVER STRETCHER 1
15 M902-10 BRAKE SHAFT M9 STRETCHER 2
16 M903-03 FOOT END ELEVATOR ASSY M9 1
17 M903-04 HEAD END ELEVATOR ASSEMBLY 3ED 1
18 M910-24 3 CHANNEL CONDUIT E ELEVATOR 1
19 M922-01 5th WHEEL M9 STRETCHER 1 See page 48
20 N/A STABILISER LINK LOW HEIGHT 2 See page 46
21 N/A TRANSMISSION ROD ASSY LOW HEIGHT 1 See page 46
22 NBRM74 D10x30 M8 SKT SHLDR BOLT ZP 2
23 NBRM76 D10x40 M8 SKT SHLDR BOLT ZP 2
24 NBRM205 M6x10 KNURLED CUP GRUB SCREW 4
25 NBRM260 M5x12 SKT CAPSCREW SS 2
26 NBRM287 M10x50 SKT CAPSCREW ZP 8
27 NBRM483 M8 NYLOC NUT ZP 4
28 NBRM2695 M6x8 SKT CAPSCREW ZP 4
29 NBRM3701 #8x1/2" PAN SQ2 SELFTAP SS 6
30 NBRM3731 #10-16x20 PAN SQ TEKS HARD SS 2
31 NBRM3737 TAPTITE M5 x 25 CSK TRIOBULAR TORX DRIVE ZP 3
32 PLRM18 GROMMET POLYTHENE NATURAL 31.8mm 1
33 ST4410 ROLLER D33d25.6x34 4
BOGIE & ELEVATORS
NOTE: FOR TRANSFER STRETCHERS WITH A 5
TH
WHEEL USE THE FOLLOWING CASTORS;
ITEM NO. PART NO. DESCRIPTION QTY.
1 CRRM801
150 LINEA CASTOR - BRAKE
3
3 CRRM803
150 LINEA CASTOR - BRAKE & A/STATIC
1
ITEM NO. PART NO. DESCRIPTION QTY.
1 CRRM801
150 LINEA CASTOR - BRAKE
2
2 CRRM802
150 LINEA CASTOR - BRAKE & STEER
1
3 CRRM803
150 LINEA CASTOR - BRAKE & A/STATIC
1
NOTE: FOR TRANSFER STRETCHERS WITHOUT A 5
TH
WHEEL USE THE FOLLOWING CASTORS;
NOTE: FOR REPLACEMENT CASTOR COVER CLIP USE THE FOLLOWING;
ITEM NO. PART NO. DESCRIPTION
1, 2 & 3 CRRM806 CLIP 5944/150 GREY WHITE RAL9002
