Technical Service Manual M9 Transfer Stretcher (M999-29, Version 11, June 2021) 43
12. TRANSFER DECK COMPLETE
ITEM NO. PART NO. DESCRIPTION QTY. REFERENCE
1 ELRM9622 LA27 BACKREST ACTUATOR 1
2 ELRM9643 LA27 KNEEBREAK ACTUATOR 1
3 ELRM9808 MJB JUNCTION BOX with UBL 1
4 FXRM772 32mm EXTERNAL CIRCLIP ZP 2
5 M710-10 POAG EARTH STUD 1
6 M904-101 COVER PANEL LEFT M9 TRANSFER 3ED 1
7 M904-102 COVER PANEL RIGHT M9 TRANSFER 3ED 1
8 M904-122 MJB BRACKET 1
9 M904-15 DECK ASSEMBLY M9 TRANSFER 3ED 1
10 M904-47 CONTROL BOX COVER PLATE 3ED 1
11 M904-68 SOCKET BED END M9 STRETCHER DARK GREY 2
12 M905-101 BACKREST STRUT BOLT 30mm 1
13 M908-45 PUSH HANDLE SUPPORT M9 STRETCHER 1
14 M910-01 HANDSET HOLDER KIT 1
15 M910-23 3 CHANNEL CONDUIT "D" DECK LEFT 1
16 M910-32 3 CHANNEL CONDUIT "P" M9 TRANSFER 1
17 M910-33 3 CHANNEL CONDUIT H DECK RIGHT 1
18 M928-01 IV POLE FOLD DOWN M9 STRETCHER 1
19 N/A SEAT SECTION COMPLETE 1 See page 44
20 N/A BACKREST COMPLETE STRETCHER 1 See page 44
21 N/A KNEE BREAK & LEG RAISE COMPLETE 1 See page 45
22 N/A 90mm FOOT END BUFFER GREY 2 See page 49
23 N/A DECK STOP COMPLETE 4 See page 45
24 N/A 90mm HEAD END BUFFER GREY 2 See page 49
25 N/A BACKREST QR COMPLETE 1 See page 49
26 N/A UNIVERSAL MOUNT RAIL AND CONTROL BOX
ASSEMBLY
1 See page 47
27 N/A PUSH BAR ASSEMBLY 1 See page 50
28 N/A CABLE BLOCK ASSEMBLY 3 See page 45
29 NBRM263 M4x30 SKT CAPSCREW ZP 2
30 NBRM270 M6x12 SKT CAPSCREW ZP 2
31 NBRM3737 TAPTITE M5 x 25 CSK TRIOBULAR SQ DRIVE ZP 13
32 NBRM3739 TAPTITE M5 x 10 PAN TRIOBULAR SQ DRIVE ZP 2
33 NBRM381 SELFTAP #8x3/4" PAN SQ SS 3
34 NBRM4021 M6x8 BUTTON SKT SCREW SS 4
35 NBRM483 M8 NYLOC NUT ZP 4
36 NBRM74 D10x30 M8 SKT SHLDR BOLT ZP 3
37 PLRM14 CABLE GROMMET 3+2 2
38 SPRM345 DAMPING GAS STRUT 50N 260mm STROKE 1
39 WARM25 D12.5M6x1.2mm FLAT WASHER ZP 2
TRANSFER DECK COMPLETE
NOTE: FOR TRANSFER STRETCHERS WITH A POWER CORD HOLDER USE THE FOLLOWING;
ITEM NO. PART NO. DESCRIPTION QT Y. REFERENCE
26 N/A
POWER CORD HOLDER AND CONTROL BOX
ASSEMBLY
1 See page 46
