4 Technical Service Manual M9 Transfer Stretcher (M999-29, Version 11, June 2021)
1. INTRODUCTION
1.4 APPLICATION ENVIRONMENT
APPLICATION ENVIRONMENT 1:
Intensive/critical care provided in a hospital where 24 hour medical supervision and constant
monitoring is required and provision of life support system/equipment used in medical procedures is
essential to maintain/improve the vital functions of the patient.
APPLICATION ENVIRONMENT 2:
Acute care provided in a hospital or other medical facility where medical supervision and monitoring
is required and medical equipment used in medical procedures may be provided to help maintain or
improve the condition of the patient.
APPLICATION ENVIRONMENT 5:
Outpatient (ambulatory) care, which is provided in a hospital or other medical facility, under medical
supervision where ME EQUIPMENT, is provided for the need of persons with illness, injury or
disability for treatment, diagnosis or monitoring.
The stretcher is only intended for use in these environments.
NOTE: This includes use in nursing homes, rehabilitation and geriatric facilities.
1.5 SAFE WORKING LOAD (SWL)
Maximum patient weight = SWL minus weight of accessories
1 x O2 cylinder = 12 kg
1 x IV pole = 1.2 kg
1 x PH pole = 6.1 kg
1 x Mattress = 12 kg
= 30 kg
MAXIMUM PATIENT WEIGHT = SWL - 30 kg
MAXIMUM SWL = 220 kg
COMPACT
M930-04 REV C
WARD
WARD
COMPACT
Keep clear during backrest & CPR operation
Keep clear during backrest & CPR operation
tneverp ot noitcnuf tuo kcol esU
eht fo tnemevom dednetninu
mroftalp troppus sserttam
Control Box Service
Remove cover plate with 5mm
hex key to access control box
Class 1 Medical Electrical Equipment Keep plugged in
whenever possible
Protective earth conductor is fitted to the fixed
wiring. Ensure that the power and handset cords
are positioned so they cannot become damaged
during bed adjustment.
Power Input: Max. 2.0A
220-240V 50-60Hz
Mode: Max. 2min/20min
Do not use in oxygen rich environments
Howard Wright Limited, Paraite Road, Bell Block, New Plymouth, New Zealand.
Call free: Australia: 1800 120 727 New Zealand: 0508 751 751
Power Input: Max. 2.0A Model:
220-240V 50-60Hz Date:
Mode: Max. 2min/20min
:
IPX4
SN
220kg
250kgMAX
220kg 250kgMAX
Potential
Equalisation
Terminal
tneverp ot noitcnuf tuo kcol esU
eht fo tnemevom dednetninu
mroftalp troppus sserttam
190mm
MAX
860mm
1900mm
Mandatory Mattress Size: Compact
190mm
MAX
860mm
2000mm
Mandatory Mattress Size: Ward
Howard Wright Limited, Paraite Road, New Plymouth, NEW ZEALAND
Part # 1:
M930-04
Part # 2:
M9 Ward and Compact 3ED
Label Set
Description:
Parent Product: M9
Drawing Size: A2
Material:Rev
Colours:
Pantone 637
Drawn
ZM
ChkdDate
16.07.13
New Artwork:
New Labels P1280
Adhesive:
Tooling: New Artwork
Polycarb .175 Matt HP40
TA9474LE
Drawing Scale: 1:1
Pantone 432U
Grey White Background - matched to HWL powdercoat sample.
DIELINE
Permark UV264
B
ZM
20.02.14
‘PLUS’ removed and typo fixed
A
Knife: 6891K1 Setup
C
TAJ
11.03.14
ECR305 - Typo fixed & plug-in symbol updated
Pink box is clear window, no print colour
NOTE: This is an indicative list. Other accessories can be used and the weight of these must be deducted.
Figure 1. Safe Working Load
