Speakers
Description Spare part number
Speaker, right 646792-001
Speaker, left 646793-001
The speakers are located at the bottom of the computer. Two screws secure each speaker. Each
speaker connects to the system board..
Figure 6-26 Speaker location
To remove the speakers:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 26).
2. Remove the rear cover (see
Rear Cover on page 27).
Speakers 45
