Memory
Description Spare part number
4-GB 646801-001
2-GB 646800-001
1-GB 647448-001
Memory modules are located on the right side of the computer (when viewed from behind) under the
memory cover. The computer has two memory slots.
Figure 6-17 Memory location
To remove a memory module:
1. Prepare the computer for disassembly (see
Preparing to Disassemble the Computer
on page 26).
2. Remove the rear cover (see
Rear Cover on page 27).
Memory 39
