Network topology icons
Represents a generic network device, such as a router, switch, or firewall.
Represents a routing-capable device, such as a router or Layer 3 switch.
Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that supports
Layer 2 forwarding and other Layer 2 features.
Represents an access controller, a unified wired-WLAN module, or the access controller
engine on a unified wired-WLAN switch.
Represents an access point.
Represents a mesh access point.
Represents omnidirectional signals.
Represents directional signals.
Represents a security product, such as a firewall, UTM, multiservice security gateway, or
load-balancing device.
Represents a security card, such as a firewall, load-balancing, NetStream, SSL VPN, IPS,
or ACG card.
Port numbering in examples
The port numbers in this document are for illustration only and might be unavailable on your device.





HP 1420 Series Specifications

General

Type	Unmanaged
Form Factor	Rack-mountable or desktop
Power Supply	Internal
Layer	Layer 2
Energy Efficient Ethernet	Yes
Management	Unmanaged
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Uplink Ports	SFP (selected models)
Fanless	Yes (selected models)
Jumbo Frame Support	Yes
Ports	8, 16, or 24 RJ-45 10/100/1000 ports or 24 RJ-45 10/100/1000 ports + 2 SFP ports
