HP 1420 Series User Manual

16
Figure 21 1420-24G-PoE+ (124W) rear panel
(1) Grounding screw (2) AC power receptacle
Technical specifications
Chassis dimensions and weights
Chassis Dimensions (H x W x D) Maximum
w
ei
g
ht
1420-16G 44 × 266 × 162 mm (1.73 × 10.47 × 6.38 in) 1.2 kg (2.65 lb)
1420-24G-2SFP 44 × 440 × 173 mm (1.73 × 17.32 × 6.81 in) 2.2 kg (4.85 lb)
1420-24G-2SFP+ 10G Uplink 44 × 440 × 238 mm (1.73 × 17.32 × 9.37 in) 2.9 kg (6.39 lb)
1420-24G-PoE+ (124W) 44 × 440 × 238 mm (1.73 × 17.32 × 9.37 in) 3.3 kg (7.28 lb)
Ports and interface card slots
Chassis
10/100/1000BASE-T
auto-sensing Ethernet
p
orts
100/1000BASE-X
SFP ports
1000BASE-X
SFP/10GBASE-SR/LR
SFP+
1420-16G 16 0 0
1420-24G-2SFP 24 2 0
1420-24G-2SFP+ 10G Uplink 24 0 2
1420-24G-PoE+ (124W)
24 (1 to 12 are PoE
ports), PoE+
0 0
Environmental specifications
Chassis O
p
eratin
g
tem
p
erature Relative humidit
y
All chassis 0°C to 40°C (32°F to 104°F) 5% to 95%, noncondensing

HP 1420 Series Specifications

General

Type	Unmanaged
Form Factor	Rack-mountable or desktop
Power Supply	Internal
Layer	Layer 2
Energy Efficient Ethernet	Yes
Management	Unmanaged
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Uplink Ports	SFP (selected models)
Fanless	Yes (selected models)
Jumbo Frame Support	Yes
Ports	8, 16, or 24 RJ-45 10/100/1000 ports or 24 RJ-45 10/100/1000 ports + 2 SFP ports
