14
Appendix A Chassis views and technical
specifications
Chassis views
1420-16G
Figure 14 1420-16G front panel
(1) 10/100/1000BASE-T copper ports
(2)
Copper port LEDs
(3) Power LED
Figure 15 1420-16G rear panel
(1) Groundin
screw (2)
C power receptacle
1420-24G-2SFP
Figure 16 1420-24G-2SFP front panel
(1) 10/100/1000BASE-T copper ports (2) 100/1000BASE-X SFP fiber ports
(3) Copper port LEDs (4) Power LED
(5) Fiber port LEDs
