MESR
System Commands
HP
1650B/HP
1651B
6-30
Programming Reference
Table
&3.
Module Event Status Register
Module Event Status Register
Bit
Weight
!
Condition
7
128
6
64
5
32
4
16
3
8
2
4
1
2
0
1
Not
used
Not
used
Not
used
Not
used
Not
used
Not
used
1 =
Run until satisified
0 = Run until not
satisified
1 =
Measurement complete
0 = Measurement not complete
103
105
