HP 1650B

SWAVeform Subsystem
14
Introduction The commands in the State Waveform subsystem allow you to configure
the display so that you can view state data as waveforms on up to 24
channels identified by label name and bit number. The five commands are
analogous to their counterparts in the Timing Waveform subsystem.
However, in this subsystem the x-axis is restricted to representing only
samples (states), regardless of whether time tagging is on or off. As a
result, the only commands which can be used for scaling are DELay and
RANGe.
The way to manipulate the X and 0 markers on the Waveform display is
through the State Listing (SLISt) subsystem. Using the marker commands
from the SLISt subsystem will affect the markers on the Waveform display.
HP 1650B/HP 1651B
Programming Reference
The commands in the SWAVeform subsystem are:
l ACCumulate
l DELay
l INSert
l RANGe
l REMove
SWAVeform Subsystem
14-1
