HP 1650B

TFORmat Subsystem
17
Introduction The TFORmat subsystem contains the commands available for the Timing
Format menu in the HP 1650B/51B logic analyzer. These commands are:
0 LABel
l REMove
l THReshold
pod-specification
name = string of up to 6 alphanumen’c characters
polarity = {POSitive 1 NEGative}
pod-specification = fonnat (integerfrom 0 to 65535) for a pod (pods are assigned in decreasing order)
value = voltage (real number) -9.9 to + 9.9
Figure 17-l. TFORmat Subsystem Syntax Diagram
HP 1650B/HP 16618
Programming Reference
TFORmat Subsystem
17-1
