HP 1650B

DATA
Machine 1 Machine 2 Pod 5 Pod 4 Pod 3 Pod 2 Pod 1*
177 Status Status Data Data Data Data Data
191 Status Status @
@ @ 63 @
205 Status Status Data Data Data Data Data
219
Status
Status
Glitch Glitch Glitch Glitch Glitch
14485 Status Status Data Data Data Data
Data
14499 Status Status Glitch Glitch Glitch Glitch Glitch
*The headings are not a part of the returned data.
@ = Invalid data
Transitional Timing Data Status Bytes. In transitional timing mode, the status bytes indicate
whether a given row in the data contains acquisition information or
transition count information.
b’ts 10-9 b’ts 8-7 bits 6-5 bits 4-3 bits 2-1
Pkd5 Pkd4
Pod 3 Pod 2 Pod 1
Each pod uses two bits to show what is being represented in the
corresponding Information bytes. Bits 10,8,6,4 and 2 are set when the
appropriate pod’s Information bytes represent acquisition data. When
that bit is clear, the next bit shows if the Information bytes represent the
fust word of a count. Together there are three possible combinations:
10 - This pod’s Information bytes contain acquisition data as obtained from
the target system.
01 - This pod’s Information bytes contain the frost word of a count.
00 - This pod’s Information bytes contain part of a count other than the
first word.
