1. Remove the four Phillips M2.0 × 7.0 screws that secure the bottom cover to the computer.
2. Use a tool (1) to release the bottom cover (2) from the computer
3. Remove the bottom cover (3).
To replace the bottom cover, reverse the removal procedures.
Battery
To remove the battery, use this procedure and illustration.
Table 5-2
Battery description and part number
Description Spare part number
Battery (4 cell, 68 Whr) N39857-005
WARNING! To avoid personal injury and damage to the product:
● Do
not
puncture, twist, or crack the battery.
Battery
31
