3. Insert the drive (1) into the socket and onto the bottom bracket.
4. Place the top bracket (2) over the drive.
5. Install the two Phillips screws (3).
NOTE: Solid-state drives are designed with a notch to prevent incorrect insertion.
WLAN module
To remove the WLAN module, use this procedure and illustration.
Table 5-4
WLAN module descriptions and part numbers
Description Spare part number
MediaTek RZ616 Wi-Fi 6E + Bluetooth 5.3 N22541-005
MediaTek MT7925 Wi-Fi 7 + Bluetooth 5.4 N64647-005
WLAN module 35
