3. Remove the top bracket from the drive, and then remove the drive from the bottom bracket.
To install the solid-state drive:
1. When installing a solid-state drive, be sure the thermal pad is installed inside of the top bracket
2. Install the bottom bracket into the computer with the tabs on the bracket sitting on top of the system
board drive socket.
34
Chapter 5 Removal and replacement procedures for authorized service provider parts
