2-20
Using the ProCurve Web Browser Interface
Web Configuration
Using the ProCurve Web
Browser Interface
Trunk Configuration
You can use the Trunk Configuration page to manually set the speed, duplex
mode, and flow control.
Modifying Trunk Settings
1. On the Trunks Configuration page, modify any of the following settings:
• Speed Duplex – Allows auto-negotiation to be enabled or disabled.
When auto-negotiation is disabled, you can force the settings for
speed, duplex mode, and flow control.
• Flow Control – Allows automatic or manual selection of flow control.
2. Click APPLY.
Note All the ports in the trunk will have the same speed, duplex mode, and flow
control as defined by the trunk. Once the trunk is deleted, the ports will no
longer be a member of that trunk but will retain the speed, duplex mode, and
flow control setting of that trunk.
Field Attributes
• Trunk – Indicates trunk identification.
• Speed/Duplex – Allows you to manually set the port speed and
duplex mode for all ports in the trunk.
• Flow Control – Allows flow control to be enabled or disabled. When
the box is checked, flow control is enabled.
• Member Ports – Indicates which ports belong to the trunk.
Web – Click Trunks, Configuration.
