HP 1910 Series Getting Started Guide

5
CAUTION:
• Hold the SFP transceiver module by its two sides when you install or remove the module. Do not touch
the golden finger of the module.
• Remove the optical fiber, if any, from a transceiver module before installing it.
To install an SFP transceiver module and connect the optical fiber:
1. Wear an ESD-preventive wrist strap and make sure it makes good skin contact and is well
grounded.
2. Pivot the clasp of the module up. Holding the module, gently push the module into the slot until it
has firm contact with the slot (when the top and bottom spring tabs catch in the slot).
3. Remove the protection covers from the optical fiber and the transceiver module, and connect the LC
connector of the optical fiber to the transceiver module.
NOTE:
Keep the protection covers for future use.
Figure 19 Installing SFP transceiver module and connecting optical fiber
Connecting the console cable
W
ARNING!
Do not connect or remove the console cable to or from the PC if the switch has been powered on.
To connect a terminal, for example, a PC, to the switch:
1. Wear an ESD-preventive wrist strap and make sure it makes good skin contact and is well
grounded.
2. Plug the DB-9 female connector of the console cable to the serial port of the PC.
3. Connect the RJ-45 connector to the console port of the switch.
Figure 20 Connecting the console cable

HP 1910 Series Specifications

General

PoE Support	No
Type	Managed
VLAN Support	Yes
MAC Address Table Size	8192 entries
Jumbo Frame Support	Yes
Operating Temperature	0°C to 45°C (32°F to 113°F)
Operating Humidity	10% to 90% (noncondensing)
Uplink Ports	4 x SFP
