HP 1910 Series

3
Figure 6 Rear panel
(1) Grounding screw (2) AC-input power receptacle
1910-8-PoE+ panel views
Figure 7 Front panel
(1) 10/100Base-T auto-sensin
g
Ethernet port (2) Combo interface
(3) Console port (4) Port LED
(5) Power LED (Power)
Figure 8 Rear panel
(1)
A
C-input power receptacle (2) Groundin
g
screw (3)
A
nti-theft hole
1910-24-PoE+ panel views
Figure 9 Front panel
(1) 10/100Base-T auto-sensin
g
Ethernet port (2) Combo interface
(3) Port LED (4) Power LED (Power)
(5) Console port
