1
Product overview
The HP 1910 Switch Series includes the models in Table 1.
Table 1 HP 1910 Switch Series models
Product code HP description Alias
Non-PoE
JG536A HP 1910-8 Switch 1910-8
JG538A HP 1910-24 Switch 1910-24
JG540A HP 1910-48 Switch 1910-48
PoE
JG537A HP 1910-8-PoE+ Switch 1910-8-PoE+
JG539A HP 1910-24-PoE+ Switch 1910-24-PoE+
1910-8 panel views
Figure 1 Front panel
(1) 10/100Base-T auto-sensin
Ethernet port
(2)
Combo
interface
(3) Console port (4) Port LED
(5) Power LED (Power)
NOTE:
The 10/100Base-T Ethernet ports of the HP 1910 switch are numbered from the upper left to the lower
right. From left to right, the ports in the upper line are numbered odd numbers 1, 3, 5, and so on, and
those in the lower line are numbered even numbers 2, 4, 6, and so on.
Figure 2 Rear panel
(1) Grounding screw (2) AC-input power receptacle (3) Anti-theft hole
