HP StorageWorks 2000 G2 Modular Smart Array Reference Guide 75
Host properties
When you select the Host component, the Properties for Host table shows:
• Host ID. WWPN or IQN.
• Name.
• Discovered. If the host was discovered and its entry was automatically created, Yes. If the host entry
was manually created, No.
• Mapped. If volumes are mapped to the host, Yes; otherwise, No.
• Profile. If the host type is Standard, LUN 0 can be assigned to a mapping. If the host type is OpenVMS,
LUN 0 cannot be assigned to a mapping. If the host type is HP-UX, LUN 0 can be assigned to a
mapping and the host uses Flat Space Addressing.
Mapping properties
When you select the Maps component, the Maps for Host table shows:
• Type. Explicit or Default. Settings for an explicit mapping override the default mapping.
• Name. Volume name.
• Serial Number. Volume serial number.
• Ports. Controller host ports through which the volume is mapped to the host.
• LUN. Volume identifier presented to the host.
• Access. Volume access type: read-write, read-only, no-access (masked), or not-mapped.
Viewing information about an enclosure
In the Configuration View panel, right-click an enclosure and select View > Overview. You can view
information about the enclosure and its components in a front or rear graphical view, or in a front or rear
tabular view.
• Front Graphical. Shows components at the front of the enclosure.
• Front Tabular. Shows information about:
•The enclosure
• Each disk
NOTE: SMU does not identify whether a disk is an SSD. To do so, select a disk and view its model
number.
• Rear Graphical. Shows components at the rear of the enclosure.
• Rear Tabular. Shows information about:
•The enclosure
• Each controller module, network port, host port, expansion port, CompactFlash card, and power
supply
• (Non-MSA70 drive enclosure) Each expansion I/O module, In port, and Out port
• (MSA70 drive enclosure) Each expansion I/O module, power supply, and fan
In any of these views, select a component to see more information about it.
