HP 470 G7 User Manual

7 Using Setup Utility (BIOS)
Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output
devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility (BIOS)
includes settings for the types of devices installed, the startup sequence of the computer, and the amount of
system and extended memory.
NOTE: To start Setup Utility on convertible computers, your computer must be in notebook mode and you
must use the keyboard attached to your notebook.
Starting Setup Utility (BIOS)
IMPORTANT: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the
computer from operating properly.
▲ Turn on or restart the computer and quickly press f10.
– or –
Turn on or restart the computer, quickly press esc, and then press f10 when the Start menu is displayed.
Updating Setup Utility (BIOS)
Updated versions of Setup Utility (BIOS) might be available on the HP website.
Most BIOS updates on the HP website are packaged in compressed les called SoftPaqs.
Some download packages contain a le named Readme.txt, which contains information regarding installing
and troubleshooting the le.
Determining the BIOS version
To decide whether you need to update Setup Utility (BIOS), rst determine the BIOS version on your computer.
To reveal the BIOS version information (also known as ROM date and System BIOS), use one of these options.
● HP Support Assistant
1. Type support in the taskbar search box, and then select the HP Support Assistant app.
– or –
Select the question mark icon in the taskbar.
2. Select My notebook, and then select Specications.
● Setup Utility (BIOS)
1. Start Setup Utility (BIOS) (see Starting Setup Utility (BIOS) on page 63).
2. Select Main, and then make note of the BIOS version.
3. Select Exit, select one of the options, and then follow the on-screen instructions.
● In Windows, press ctrl+alt+s.
Starting Setup Utility (BIOS) 63

HP 470 G7 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
LED backlight	Yes
RGB color space	NTSC
Display diagonal	17.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	300 cd/m²
Native aspect ratio	16:9
NTSC coverage (typical)	72 %
Display diagonal (metric)	43.9 cm
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	2666 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
Number of built-in speakers	2
Front camera HD type	HD
Front camera signal format	720p
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
MIMO type	Multi User MIMO
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
WLAN controller manufacturer	Intel
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Thunderbolt 3 ports quantity	0
Pointing device	Touchpad
Sustainability certificates	ENERGY STAR
AC adapter power	65 W
Cable lock slot type	Kensington
Battery capacity	41 Wh
Number of battery cells	3
HP segment	Business
HP speaker type	HP Dual Speakers
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-10510U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1528
Processor threads	8
Processor codename	Comet Lake
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Processor cache type	L3
Configurable TDP-down	10 W
Processor lithography	14 nm
PCI Express slots version	3.0
Processor boost frequency	4.9 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.3 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	16
Discrete GPU manufacturer	AMD
Number of execution units	24
On-board graphics card ID	0x9B41
Discrete graphics card model	AMD Radeon 530
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Processor ARK ID	196449
Processor package size	46 x 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0

Weight and Dimensions

Depth	272 mm
Width	414.8 mm
Height	24.5 mm
Weight	2360 g
