HP 470 G7 User Manual

c. Select Hard Drive Utilities.
d. Under Utilities, select Disk Sanitizer, select the hard drive storing the data you want to clear, and
then follow the on-screen instructions to continue.
Nonvolatile memory usage
Table 11-1 Troubleshooting steps for nonvolatile memory usage
Nonvolatile
memory type Amount (Size)
Does this
memory
store
customer
data?
Does this
memory
retain data
when power
is removed?
What is the
purpose of this
memory?
How is data entered into this
memory?
How is this memory
write-protected?
HP Sure Start ash
(select models
only)
8 MB No Yes Provides
protected
backup of
critical System
BIOS code, EC
rmware, and
critical
computer
conguration
data for select
platforms that
support HP
Sure Start.
For more
information,
see Using HP
Sure Start
(select models
only)
on page 82.
Data cannot be written to this
device via the host processor.
The content is managed
solely by the HP Sure Start
Embedded Controller.
This memory is protected
by the HP Sure Start
Embedded Controller.
Real Time Clock
(RTC) battery
backed-up CMOS
conguration
memory
256 bytes No Yes Stores system
date and time
and noncritical
data.
RTC battery backed-up CMOS
is programmed using
Computer Setup (BIOS), or by
changing the Microsoft®
Windows date & time.
This memory is not write-
protected.
Controller (NIC)
EEPROM
64 KB (not
customer
accessible)
No Yes Stores NIC
conguration
and NIC
rmware.
NIC EEPROM is programmed
using a utility from the NIC
vendor that can be run from
DOS.
A utility must be used to
write data to this memory
and is available from the
NIC vendor. Writing data
to this ROM in an
inappropriate manner will
render the NIC non-
functional.
DIMM Serial
Presence Detect
(SPD)
conguration data
256 bytes per
memory
module, 128
bytes
programmable
(not customer
accessible)
No Yes Stores memory
module
information.
DIMM SPD is programmed by
the memory vendor.
Data cannot be written to
this memory when the
module is installed in a
computer. The specic
write-protection method
varies by memory vendor.
Nonvolatile memory usage 79

HP 470 G7 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
LED backlight	Yes
RGB color space	NTSC
Display diagonal	17.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	300 cd/m²
Native aspect ratio	16:9
NTSC coverage (typical)	72 %
Display diagonal (metric)	43.9 cm
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	2666 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
Number of built-in speakers	2
Front camera HD type	HD
Front camera signal format	720p
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
MIMO type	Multi User MIMO
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
WLAN controller manufacturer	Intel
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Thunderbolt 3 ports quantity	0
Pointing device	Touchpad
Sustainability certificates	ENERGY STAR
AC adapter power	65 W
Cable lock slot type	Kensington
Battery capacity	41 Wh
Number of battery cells	3
HP segment	Business
HP speaker type	HP Dual Speakers
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-10510U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1528
Processor threads	8
Processor codename	Comet Lake
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Processor cache type	L3
Configurable TDP-down	10 W
Processor lithography	14 nm
PCI Express slots version	3.0
Processor boost frequency	4.9 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.3 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	16
Discrete GPU manufacturer	AMD
Number of execution units	24
On-board graphics card ID	0x9B41
Discrete graphics card model	AMD Radeon 530
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Processor ARK ID	196449
Processor package size	46 x 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0

Weight and Dimensions

Depth	272 mm
Width	414.8 mm
Height	24.5 mm
Weight	2360 g
