HP 470 G7 User Manual

Table 11-1 Troubleshooting steps for nonvolatile memory usage (continued)
Nonvolatile
memory type Amount (Size)
Does this
memory
store
customer
data?
Does this
memory
retain data
when power
is removed?
What is the
purpose of this
memory?
How is data entered into this
memory?
How is this memory
write-protected?
System BIOS 9 MB Yes Yes Stores system
BIOS code and
computer
conguration
data.
System BIOS code is
programmed at the factory.
Code is updated when the
system BIOS is updated.
Conguration data and
settings are entered using
the Computer Setup (BIOS) or
a custom utility.
NOTE: Writing data to
this ROM in an
inappropriate manner can
render the computer non-
functional.
A utility must be used for
writing data to this
memory and is available
on the HP website; go to
http://www.hp.com/
support. Select Find your
product, and then follow
the on-screen
instructions.
Intel Management
Engine Firmware
(present only in
select Elite or Z
models. For more
information, go to
http://www.hp.com/
support. Select
Find your
product, and then
follow the on-
screen
instructions.)
1.5 MB or 7 MB Yes Yes Stores
Management
Engine Code,
Settings,
Provisioning
Data and iAMT
third-party data
store.
Management Engine Code is
programmed at the factory.
Code is updated via Intel
secure rmware update
utility. Unique Provisioning
Data can be entered at the
factory or by an
administrator using the
Management Engine (MEBx)
setup utility. The third-party
data store contents can be
populated by a remote
management console or local
applications that have been
registered by an
administrator to have access
to the space.
The Intel chipset is
congured to enforce
hardware protection to
block all direct read/write
access to this area. An
Intel utility must be used
for updating the
rmware. Only rmware
updates digitally signed
by Intel can be applied
using this utility.
Bluetooth ash
(select products
only)
2 Mb No Yes Stores
Bluetooth
conguration
and rmware.
Bluetooth ash is
programmed at the factory.
Tools for writing data to this
memory are not publicly
available but can be obtained
from the silicon vendor.
A utility must be used for
writing data to this
memory and is made
available through newer
versions of the driver
whenever the ash
requires an upgrade.
802.11 WLAN
EEPROM
4 Kb to 8 Kb No Yes Stores
conguration
and calibration
data.
802.11 WLAN EEPROM is
programmed at the factory.
Tools for writing data to this
memory are not made public.
A utility must be used for
writing data to this
memory and is typically
not made available to the
public unless a rmware
upgrade is necessary to
address a unique issue.
Webcam (select
products only)
64 Kb No Yes Stores webcam
conguration
and rmware.
Webcam memory is
programmed using a utility
from the device
manufacturer that can be run
from Windows.
A utility must be used for
writing data to this
memory and is typically
not made available to the
public unless a rmware
80 Chapter 11 Statement of memory volatility

HP 470 G7 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
LED backlight	Yes
RGB color space	NTSC
Display diagonal	17.3 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	300 cd/m²
Native aspect ratio	16:9
NTSC coverage (typical)	72 %
Display diagonal (metric)	43.9 cm
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	2666 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
Number of built-in speakers	2
Front camera HD type	HD
Front camera signal format	720p
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express, NVMe
Storage media	SSD
Total storage capacity	256 GB
Number of SSDs installed	1
MIMO type	Multi User MIMO
Antenna type	2x2
Bluetooth version	5.0
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
WLAN controller manufacturer	Intel
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Thunderbolt 3 ports quantity	0
Pointing device	Touchpad
Sustainability certificates	ENERGY STAR
AC adapter power	65 W
Cable lock slot type	Kensington
Battery capacity	41 Wh
Number of battery cells	3
HP segment	Business
HP speaker type	HP Dual Speakers
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-10510U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1528
Processor threads	8
Processor codename	Comet Lake
Configurable TDP-up	25 W
Processor frequency	1.8 GHz
Processor cache type	L3
Configurable TDP-down	10 W
Processor lithography	14 nm
PCI Express slots version	3.0
Processor boost frequency	4.9 GHz
Processor operating modes	64-bit
PCI Express configurations	1x4, 2x2, 1x2+2x1, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.3 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	16
Discrete GPU manufacturer	AMD
Number of execution units	24
On-board graphics card ID	0x9B41
Discrete graphics card model	AMD Radeon 530
On-board graphics card model	Intel® UHD Graphics
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.5
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Processor ARK ID	196449
Processor package size	46 x 24 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0

Weight and Dimensions

Depth	272 mm
Width	414.8 mm
Height	24.5 mm
Weight	2360 g
