lA.
Function
Test
Using
the
HP
81533A
The
Function
Tbst
given
in
this
section
is
using
the
HP
81533A
Optical
Head
Interface
Module
and
the
08152-63201
Test/Cal
Box
to
check
voltages
and
signals
from
and
to
the
HP8153A
Multimeter
Mainframe.
Note
If
you
do
not
have
an
HP
81633A
or
a
Test/Cal
Box,
it
is
possible
to
perform
the
function
lest
with
other
modules.
Go
to
“IB.
Function
Ihst
using
a
HP
81530/31/32
or
HP
81536A".
Perform
each
step
in
the
tests
in
the
order
they
are
given
using
the
corresponding
test
equipment.
Display
Function
and
Module
Interface
Tests
Display
Function
Tests
1.
Insert
the
HP81533A
into
the
Multimeter
channel
A
position
and
connect
the
Test/Cai
Box
to
the
HP8153A
Input.
2.
Make
sure
that
the
Head
Recognition
Adapter
is
connected
to
the
Test/Cal
Box.
3.
Turn
power
on
and
check
that
all
display
segments
are
lit
for
approx.
2
seconds
and
the
HP8153A
displays
E
3200
HEAD-DAT
SELFTEST.
4.
Press
any
key
on
the
I-IP8163A
to
overwrite
the
error
message.
5.
Press
the
[Param]
key
until
PARAM=
CAL
is
displayed.
6.
Using
the
[Modify]
keys
check
that
the
CAL
factor
can
be
changed
200.000dB
to
-200.000dB
amd
set
the
CAL
factor
back
to
O.OOOdB
by
holding
the
[Param]
key
down
for
approx.
3
second.s.
7.
Press
the
[Param]
key
until
PARAM=
T
is
displayed.
8.
Using
the
[Modify]
keys
check
that
following
measurement
time
settings
can
be
selected:
60,
30,
20,
15,
10,
5,
2,
1
minutes.
30,
20,
10,
5,
2,
1
seconds.
500,
200,
100,
60,
20
miliseconds.
9.
Select
display
in
[dBm]
and
press
the
[Param]
key
until
PARAM
=
REF
is
displayed.
Function
Tests
D-3
