(mD
(Exec)
(Pause)
(Prey)
(Next)
# 1
ALIGNMNT TYPE
DELTA
shows the first of the samples taken. Ih
examine the rest of the samples, use the
Modify keys.
sets whether the instrument automatically
records the maximum power-level, or the
user sets the maximum power-level,
sets the range of power shown by the
graphic bar.
sets the maximum power-level.
MAXPOWER
enables or disables the editing of parameters.
Runs or stops an application.
Pauses or continues an application.
selects the previous in a series of applications or parameters,
selects the next in a seris of applications or parameters.
System Mode
The mode-indicator shows MEMU SYS at the top of the display.
RECALL Recall a configuration that is stored in memory.
■ The module type is indicated by the last two numeric digits of
the product number.
■ The location where the configuration data is stored. This number
is displayed to the left of the arrow.
The channel is either the letter A or the letter B. It is displayed
to the right of the arrow.
STORE Store a configuration into memory.
■ The module type is shown for the last data that was stored in
the selected location.
■ The channel is either the letter A or the letter B. It is displayed
to the left of the arrow.
■ The location where the configuration data will be stored is a
number between 1 and 9. This number is displayed to the right
of the arrow.
HPIB Set the HP-IB parameters.
ADDRESS to set the HP-IB address of the instrument.
MODE to set the instrument to control or talk-only
operation.
Local Control Summary F-3
