from a Manual Logging application. The units of time can be seconds, minutes
or hours.
■ The graph is of the power as a function of time for the Stability or Logging
applications. The graph is of power as a function of the number of samples
taken for the Manual Logging application.
■ Horizontal dotted lines are drawn on the graph at the maximum, minimum
and average power-levels sampled.
The More Key
(Morel gets you iiito the other applications. The full list of these applications
depends on the modules that you have installed. There are two that are
standard, these come with the mainframe. They are the show and the alignment
applications.
After pressing (More) , you choose an application using (Next I (Morel or (prevl . (Morel
acts in the same way as (Nextl . The application is displayed in the character field
of the selected channel.
The Show Application
In the Show application you can look at the samples from a Stability or Logging
application. You can only look at the samples from the most recent Stability or
Logging or Manual Logging application.
When you select the Show application the character field shows SHOW. This
application has no parameters that can be modified.
Press (Editl to look at the stored values. While you are looking at the stored
values, the EDIT operation-indicator lights. To move from one value to another
you use (Prev) and (Next) .
MAXIMUM
When MAXIMUM shows in the left side character field, the value in the right side
character field is the maximum power-level sampled.
MINIMUM
3-22 Local Control - Menu Mode
