HP 86140A Series User Manual

1-7
Setting Up the OSA
Setting Up the OSA
The optical spectrum analyzer automatically adjusts for line input voltages in
the range of 100 to 240 VAC. There is no manual selection switch. The line
cord provided is matched by HP to the country of origin of the order. Refer to
“AC Line-Power Cords” on page 6-4.
Line Power Requirements
Power 115 VAC: 110 VA MAX. / 60 WATTS MAX. / 1.1 A MAX.
230 VAC: 150 VA MAX. / 70 WATTS MAX. / 0.6 A MAX.
Voltage nominal: 115 VAC / 230 VAC
range 115 VAC: 90–132 V
range 230 VAC: 198–254 V
Frequency nominals: 50 Hz / 60 Hz
range: 47–63 Hz
book.book Page 7 Monday, January 31, 2000 10:34 AM

HP 86140A Series Specifications

General

Brand	HP
Model	86140A Series
Category	Measuring Instruments
Language	English
