HP 86140A Series User Manual

3-57
Using the Optical Spectrum Analyzer
The Traces Menus
Using the Traces functions
To set the active trace
1
Press the front-panel
Traces
key.
2
Press the
Active Trace....
softkey.
3
Use the arrow keys or knob to select the active trace.
or
1
Press the front-panel
Markers
key.
2
Press the
Active Trace....
softkey.
3
Use the arrow keys or knob to select the active trace.
To put a marker on a trace, or to make changes to a trace, it must be the active
trace. The active trace is designated by the double-arrows at either the left or
right edge of the graticule.
To set the update function for the trace
1
Press the front-panel
Traces
key.
2
Select the trace to be changed.
3
Press the
Update <trace>
softkey.
4
Use the arrow keys or knob to select
ON
or
OFF
.
When
ON
, the trace always accepts data when data is available.
When
OFF
, the trace will not be updated.
To set the display function for the trace
1
Press the front-panel
Traces
key.
2
Select the trace to be changed.
3
Press the
View <trace>
softkey to turn the display of the selected trace
ON
or
OFF
.
