HP 86140A Series User Manual

4-53
Remote Operation
CALCulate Subsystem Commands
CALCulate:MARKer[1|2|3|4]:MAXimum:LEFT
Places the marker on the next peak located at a shorter wavelength than the
current marker wavelength position. This next peak must meet the peak
excursion and threshold criteria. If the specified marker is
OFF
, it will be
turned
ON
, placed at the center wavelength, and the search to the left will
begin from that point.
CALCulate:MARKer[1|2|3|4]:MAXimum:NEXT
Places the marker on the next highest peak from the current marker ampli-
tude. This next highest peak must meet the peak excursion and threshold cri-
teria. If the specified marker is
OFF
, it will be turned
ON
, placed at the center
wavelength, and the search for the next maximum will begin from that point.
CALCulate:MARKer[1|2|3|4]:MAXimum:RIGHt
Places the marker on the next peak located at a longer wavelength than the
current marker wavelength position. This next peak must meet the peak
excursion and threshold criteria. If the specified marker is
OFF
, it will be
turned
ON
, placed at the center wavelength, and the search to the right will
begin from that point.
CALCulate:MARKer[1|2|3|4]:MINimum
Places the specified marker on the lowest point of the trace. The point does
not
have to meet the pit excursion and threshold criteria. The marker trace is
determined by the CALCulate:MARKer:TRACe command. If the specified
marker is
OFF
, it will be turned
ON
and placed on the lowest point of the trace.
CALCulate:MARKer[1|2|3|4]:MINimum:LEFT
Places the marker on the next pit located at a shorter wavelength than the
current marker wavelength position. This next pit must meet the pit excursion
and threshold criteria. If the specified marker is
OFF
, it will be turned
ON
,
placed at the center wavelength, and the search to the left will begin from that
point.
book.book Page 53 Monday, January 31, 2000 10:34 AM
