HP 8712ES User Guide Supplement

Automating Measurements 8-7
Saving Measurement Results
Saving Measurement Results to Disk
Saving Measurement Results to Disk
The analyzer provides two internal RAM disks and one internal 3.5 inch
floppy disk to which measurement results can be saved.
For the fastest saves, measurements should be saved to RAM disk. From
RAM disk, they can be copied to the internal floppy disk by pressing
, or using the SCPI
command
MMEM:COPY 'MEM:*.*', 'INT:'
or
MMEM:COPY 'RAM:*.*', 'INT:'
The following mass storage specifiers can be used:
Table 8-1 Mass Storage Specifiers
The files can also be transferred over HP-IB using the SCPI command
MMEM:TRANsfer. Refer to the Example Programs Guide for details.
SAVE RECALL
File Utilities
Copy All Files
Disk SCPI name
Non-Volatile RAM Disk
Volatile RAM Disk
Internal 3.5 in Disk
MEM:file
RAM:file
INT:file
