5
1.1 meter System Rack (HP C2785A)
2
1.1 meter System Rack (HP C2785A)
The 1.6 meter system rack incorporates a ventilation path through the top
cover. This enables removal of system-generated heat through natural
convection. For greater heat dissipation, an optional extractor fan unit is
available. The unit mounts in the top of the rack. The standard 1.1 meter rack
is provided with a non-vented top (unless the extractor fan option is
specified).
A vented rear door is standard. A lockable latch is provided to prevent
unauthorized removal of system components. The rear door is symmetrical,
so that it can be mounted to open from left or right.
0.6 meters
100 mm extra space
for cable management
and cooling
0.9 meters
Optional anti-tip ballast
C2790A - 14 kg
Anti-tip bracket
Note: Castors included as standard
3 EIA unit filler panels
1.1 meters
