DTC Connectors
8
DTC Connectors
DTC 62-pin connector
This connector can be purchased from AMP.
Note The maximum cable diameter is determined by the ferrule used. It is 14.27 mm or
.562 inches.
HDP-22 Plug Connector
Plug Enclosure Kit Number 748476-1
Pin Contact Number 748333-2
AMP Insertion/Extraction Tool 91285-1
AMP Hand Crimping Tool 543344-1
AMP Shielding Enclosure Expansion Tools 58241-1,2
MALE
FEMALE
1
22
43
21
42
62
43
22
1
62
42
21
