Racking the Modem Distribution Panel HP J2085 #101
4
Racking the Modem Distribution Panel HP J2085 #101
Front Mounting
Accessories are available for mounting MDPs in the system rack. Illustrated
below is product HP J2084A, which uses 7 EIA units. It is a metal mounting
panel, with a filler panel, which enables front mounting of up to five Modem
Distribution Panels in the system rack. An alternative product, HP J2087A,
enables front or rear mounting of up to 5MDPs (with no filler panel).
1 Attach the mounting panel to the rack using 4 screws from your rack kit.
Note The panel is correctly oriented when the cable-access slots are towards the bottom of
the panel.
