DTC Connector Pinouts

V.35 X.25 interface

103a TXA 21

103b TXb 42

104a RXa 20

104b RXb 41

113a TSEb/DTE 61

113b TSEb/DTE 62

114a TSEa/DCE 19

114b TSEb/DCE 40

115a RSEa/DCE 18

115b RSEb/DCE 39

105 RTS 57

106 CTS 4

109 DCD 6

108 DTR 58

107 DSR 46

125 RI 48

102 SG 9

102b RC 47

-50

-52

-22

-23

-24

-25

-26

-27

- CA 30

- CB 31

- CC 32

- CD 60

- PG SHIELD
