RS-232 connection

Note To be used with US modem behavior only.

Recommended HP cable: HP 40220 to HP2334/5 for printer access

(depends upon termtype used HP3000 and upon

type of printer).

25-pin male connector to DTC

1 - PGND -

2 - RD INPUT

3 - TD OUTPUT

4 - DCD INPUT

5 - GPO OUTPUT

6 - DTR OUTPUT

7 - SGND -

8 - RTS OUTPUT

20 - DSR INPUT

22 - CTS INPUT

25-pin female connector to

HP 2334/5

1 - PGND -

3 - TD OUTPUT

2 - RD INPUT

8 - DCD OUTPUT

6 - DRS OUTPUT

20 - DTR INPUT

7 - SGND -

4 - RTS INPUT

5 - CTS OUTPUT
