Tasks
Remarks
Configuring LM
Optional
Configuring one-way DM
Optional
Configuring two-way DM
Optional
Configuring TST
Optional
NOTE:
A port blocked by STP cannot receive or send CFD messages except in the following cases:
 The port is configured as an outward-facing MEP.
 The port is configured as a MIP or inward-facing MEP, which can still receive and send CFD messages except
CCM messages.
Configuring basic CFD settings
Enabling CFD
Enable CFD on all concerned devices.
Follow these steps to enable CFD on a device:
To do...
Use the command...
Remarks
Enter system view
system-view
—
Enable CFD
cfd enable
Required
Disabled by default.
Configuring the CFD protocol version
Three CFD protocol versions are available: IEEE 802.1ag draft5.2 version, IEEE 802.1ag draft5.2 interim
version, and IEEE 802.1ag standard version. Devices in a same MD must use the same CFD protocol
version. Otherwise, they cannot exchange CFD protocol packets.
Follow these steps to configure the CFD protocol version:
To do...
Use the command...
Remarks
Enter system view
system-view
—
Configure the CFD protocol
version
cfd version { draft5 | draft5-plus
| standard }
Optional
By default, CFD uses the standard
version of IEEE 802.1ag.
Configuring service instances
Before configuring the MEPs and MIPs, you must first configure service instances. A service instance is a
set of service access points (SAPs), and it belongs to an MA in an MD.
