Task
Remarks
Configuring RRPP timers
Optional
Perform this task on the master node in the RRPP domain.
Configuring an RRPP ring group
Optional
Perform this task on the edge node and assistant-edge node
in the RRPP domain.
Creating an RRPP domain
When creating an RRPP domain, specify a domain ID, which uniquely identifies an RRPP domain. All
devices in the same RRPP domain must be configured with the same domain ID.
Perform this configuration on devices you want to configure as nodes in the RRPP domain.
Follow these steps to create an RRPP domain:
To do…
Use the command…
Remarks
Enter system view
system-view
—
Create an RRPP domain, and
enter RRPP domain view
rrpp domain domain-id
Required
Configuring control VLANs
Before configuring RRPP rings in an RRPP domain, configure the same control VLANs for all nodes in the
RRPP domain.
Perform this configuration on all nodes in the RRPP domain to be configured.
Follow these steps to configure control VLANs:
To do…
Use the command…
Remarks
Enter system view
system-view
—
Enter RRPP domain view
rrpp domain domain-id
—
Specify the primary control VLAN
for the RRPP domain
control-vlan vlan-id
Required
NOTE:
 When you configure existing VLANs as control VLANs, the system prompts errors.
 To ensure proper forwarding of RRPPDUs, do not enable QinQ on the control VLANs.
 To ensure that RRPPDUs can be sent and received correctly, do not configure the default VLAN of a port
accessing an RRPP ring as the primary control VLAN or the secondary control VLAN.
 To transparently transmit RRPPDUs on a device not configured with RRPP, you must ensure that only the two ports
connecting the device to the RRPP ring permit the packets of the control VLANs. Otherwise, the packets from
other VLANs may go into the control VLANs in transparent transmission mode and strike the RRPP ring.
