Appendix A Technical specifications
Table 9 describes the technical specifications for the A5500 HI switches.
Table 9 HP A5500 HI switches technical specifications
Item A5500-24G-4SFP HI (2 slots) A5500-48G-4SFP HI (2 slots)
Dimensions (H × W × D)
43.6 × 440 × 360 mm
(1.72 × 17.32 × 14.17 in)
43.6 × 440 × 420 mm
(1.72 × 17.32 × 16.54 in)
Weight < 7.5 kg (16.53 lb) < 8.5 kg (18.74 lb)
Management ports 1 console port, 1 management Ethernet port, both on the front panel
Fixed network ports (on
the front panel)
• 24 × 10/100/1000Base-T
auto-sensing Ethernet ports
• 4 × 100/1000Base-X SFP ports
• 2 × 1/10 Gbps SFP+ ports
• 48 ×10/100/1000Base-T
auto-sensing Ethernet ports
• 4 × 100/1000Base-X SFP ports
• 2 x 1/10 Gbps SFP+ ports
Expansion interface
card slots
2 (SLOT1 and SLOT2), on the rear panel
2 (SLOT1 and SLOT2), on the rear panel
Power supply slots 2, on the rear panel 2, on the rear panel
Input voltage
• AC-input
{ Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
{ Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
• DC-input
{ Rated voltage range: –48 VDC to –60 VDC
{ Max voltage range: –36 VDC to –72 VDC
NOTE:
You can use the site –48 VDC power supply or an HP A-RPS800 (JD183A) or
A-RPS1600 (JG136A) RPS as the DC power source.
Minimum power
consumption
62 W 94 W
Maximum power
consumption
141 W 191 W
Chassis leakage current
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Melting current of
power supply fuse
• AC-input: 3.15A/250V
• DC-input: 8A/250V
Cooling system
• 4 built-in fans (3 for the chassis, 1 for interface card slot 1)
• 1 fan on each power supply
• Side-to-side air flow
Operating temperature 0°C to 50°C (32°F to 122°F)
