HP A5820X Series - OAP Card Status LED; Poe Module Status LED; Interface Card Status LED

110
OAP card status LED
The SLOT3 LED on the front chassis panel shows the status of the card in the OAP card slot.
Table 36 OAP card status LED description
LED mark
Status
Description
SLOT3
Green
An OAP card is in the slot and operating properly.
Flashing yellow (1 Hz)
The slot does not support the OAP card model, or the OAP
card has failed.
Off
The OAP card slot is empty.
PoE module status LED
The SLOT4 LED shows the status of the PoE module.
Table 37 PoE module status LED description
LED mark
Status
Description
SLOT4
Green
The PoE module is in position and operating properly.
Flashing yellow (1 Hz)
The switch does not support the PoE module model, or the
PoE module has failed.
Off
The PoE module slot is empty.
Interface card status LED
The SLOT1 LED shows the status of the interface card or the OAP card in the expansion interface card
slot.
Table 38 Interface card status LED description
LED mark
Status
Description
SLOT1
Green
The interface card or the OAP card is in position and
operating properly.
Flashing yellow (1 Hz)
The slot does not support the card model, or the card has
failed.
Off
The expansion interface card slot is empty.
