Local port operation 22
Button Function
Broadcast Controls multiple servers simultaneously through keyboard and mouse actions.
Scan Sets up custom scan patters for up to 16 servers.
Security Sets password to restrict server access. A valid password must be alphanumeric and
contain a minimum of five characters and a maximum of 15 characters. Permitted
characters are case sensitive and can consist of A–Z, 0–9, spaces and hyphens.
Enables the Screen Saver mode.
Switch Changes the Switch mode to preemptive or cooperative.
Keyboard Changes the keyboard country code reported by the interface adapter if queried.
Language Enables a user to change the language displayed in the OSD. Changes the
language for help text, key mapping, and all screens.
Devices Identifies device types attached to the console switch, including servers and other
legacy console switches. You can also modify the type of legacy console switches.
Names Enables you to name the interface adapter.
Changing the display behavior
From the Menu dialog box ("Accessing the Menu dialog box" on page 22), the display order of servers,
HP KVM Server Console Switch G2 connection mode, and a time to delay display of the OSD after
pressing the Print Scrn key can be changed. The display order setting alters how servers display in several
screens, including the Main, Devices, and Broadcast dialog boxes.
Accessing the Menu dialog box
To access the Menu dialog from the Main dialog box ("Accessing the Main dialog box" on page 17),
click Setup>Menu. The Menu dialog box appears.
Selecting the display order of servers
1. From the Menu dialog box ("Accessing the Menu dialog box" on page 22), select Name to display
servers alphabetically by name.
