HP Apollo 4510 Gen10 - Management Module Components; Management Module Leds

Management module components
1
6
2
3
4
5
Item Description
1 Reserved
2 APM connector
3 iLO port 1 (RJ-45)
4 iLO port 2 (RJ-45)
5 Management module release lever
6 Management module thumbscrew
Management module LEDs
1
2
1
2
3
4
Item Description
1 iLO (RJ-45) port link LEDs
2 iLO (RJ-45) port activity LEDs
3 Chassis health LED
4 Chassis UID LED
58 Management module components
