Removing and replacing a fan louver
Procedure
1. Power down the server on page 24.
2. Remove the midplane assembly cover (Removing and replacing a midplane assembly on page
38).
3. Remove the fan louver.
To replace the component, reverse the removal procedure.
Removing and replacing the drive drawer assembly
Procedure
1. Extend the drive drawer from the chassis on page 25.
2. Remove all drives from the drawer (Removing and replacing a drive on page 34).
3. Release the rails together, and then extend the drive drawer further.
40 Removing and replacing a fan louver
