HP Apollo 4510 Gen10 - Pcie Slot Definitions

PCIe slot definitions
2
3
4
1
Item Description
1 PCIe expansion slot 1 — PCIe3 x16 (16, 8, 4, 2, 1)
2 PCIe expansion slot 2 — PCIe3 x16 (16, 8, 4, 2, 1)
3 PCIe expansion slot 3 — PCIe3 x16 (16, 8, 4, 2, 1)
4 FlexibleLOM slot — PCIe3 x8 (8, 4, 2, 1)
PCIe3 x8 (8,4,1)
Negotiable link width(s)
Physical connector link width
Gen 3 signaling rate
PCIe slot description
60 PCIe slot definitions
