HP workstation c8000 — Getting Started 1–5
Hardware Setup
Front Panel Features
The HP workstation c8000 front panel has the features identified in
the following figures.
Also note that:
■ A pull-out information tab is on the side of the system. This
tab contains the UUID, product and serial numbers. See the
figures on page 2-4.
■ For more information about the system LEDs, see
“Troubleshooting with the System LEDs” on page 4-6 and the HP
workstation c8000 Technical Reference Guide.
Front panel, tower configuration
1 System speaker 6 LAN activity LED
2 Three optical drive bays 7 Two USB connectors
3 System status LED 8 Headphone (option)
4 Power button 9 Microphone (option)
5 Disk activity LED - IEEE-1394 FireWire (option)
