HP workstation c8000 — Getting Started 1–7
Hardware Setup
Rear Panel Features
The HP workstation c8000 rear panel has the following connectors
and features:
Rear panel, tower configuration
1 Power supply LED
(inside power supply)
7 LAN connector and LEDs
2 Power cord connector 8 Three USB connectors
3 PCI/AGP retention release 9 Two serial connectors
(top connector is serial port A;
bottom connector is serial port B)
4 External SCSI connector
(option)
- Diagnostic LEDs
5 Security cable slot q Transfer-of-control (TOC) button
6 Monitor connector
(on graphics card)
